Corrosion Resistant Stainless Steel Sheet with Custom Size and Multiple Surface Finishes
商品の詳細
| 幅 | 100mm | 2000mm | 厚さ | 0.2mm～100mm |
|---|---|---|---|
| 厚さの耐性 | +/-0.01mm | 表面仕上げ | 2B、BA、8Kミラー、絞りHL、Nチタンメッキ、エッチング、エンボス |
| エッジタイプ | ミルエッジ、スリットエッジ | 製造技術 | コールドロール /ホットロール |
| 炭素含有量 | ≤0.03% | マンガンの内容 | ≤2.0% |
| リン含有量 | ≤0.03% | 硫黄分 | ≤0.02％ |
| シリコン含有量 | ≤0.80% | クロムの内容 | 21.0～23.0% |
| ニッケル含有量 | 23.0～25.0% | モリブデン含有量 | 2.5〜3.5% |
| 長さ | カスタム | ||
| ハイライト | Corrosion Resistant Stainless Steel Sheet,Custom Size SS Sheet,Multiple Surface Finishes Metal Sheet |
||
製品の説明
202 Stainless Steel Sheet
Premium Stainless Steel Sheets
Engineered for superior performance and durability, our stainless steel sheets offer exceptional corrosion resistance and aesthetic appeal. Available in a wide range of grades and finishes to meet the demands of diverse industrial applications.
- Superior Corrosion Resistance
- Exceptional Durability
- Versatile Grade Options
- Multiple Surface Finishes
Ideal Applications: Construction, Shipbuilding, Railway Stations, Medical Equipment, Food Industry, Tableware, Chemical Industry, and decorative applications.
Product Gallery
Product Specifications
Brand
N/A
Origin
N/A
Material
Stainless Steel
Color
Metallic Silver
Length
Custom
Thickness
0.3mm - 3mm
Width
1219mm or Custom
Packaging
Standard Seaworthy Package - Wooden Pallet
Technical Specifications
| Stainless Steel Grade | Standard | Width | Thickness |
|---|---|---|---|
| Stainless Steel Sheet | ASTM/ASME 240/480, JIS 4305, DIN EN 10088-2 | 100mm ~ 2000mm | 0.2mm ~ 100mm |
Chemical Composition by Grade
| UNS | ASTM | EN | JIS | C% | Mn% | P% | S% | Si% | Cr% | Ni% | Mo% |
|---|---|---|---|---|---|---|---|---|---|---|---|
| S30100 | 301 | 1.4319 | SUS301 | ≤0.15 | ≤2.00 | ≤0.045 | ≤0.03 | ≤1.00 | 16.0-18.0 | 6.0-8.0 | - |
| S30400 | 304 | 1.4301 | SUS304 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 18.0-20.0 | 8.0-10.5 | - |
| S30403 | 304L | 1.4306 | SUS304L | ≤0.03 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 18.0-20.0 | 8.0-12.0 | - |
| S30908 | 309S | 1.4833 | SUS309S | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 22.0-24.0 | 12.0-15.0 | - |
| S31008 | 310S | 1.4845 | SUS310S | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤1.50 | 24.0-26.0 | 19.0-22.0 | - |
| S31600 | 316 | 1.4401 | SUS316 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| S31603 | 316L | 1.4404 | SUS316L | ≤0.03 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| S31703 | 317L | 1.4438 | SUS317L | ≤0.03 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 18.0-20.0 | 11.0-15.0 | 3.0-4.0 |
| S32100 | 321 | 1.4541 | SUS321 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 17.0-19.0 | 9.0-12.0 | - |
| S34700 | 347 | 1.4550 | SUS347 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 17.0-19.0 | 9.0-13.0 | - |
| S32750 | SAD2507 | 1.4410 | N/A | ≤0.03 | ≤1.2 | ≤0.035 | ≤0.02 | ≤0.80 | 24.0-26.0 | 6.0-8.0 | 3.0-5.0 |
| S31803 | SAF2205 | 1.4462 | N/A | ≤0.03 | ≤2.0 | ≤0.03 | ≤0.02 | ≤1.00 | 21.0-23.0 | 4.0-6.5 | 2.5-3.5 |
| N08904 | 904L | 1.4539 | N/A | ≤0.03 | ≤2.0 | ≤0.035 | ≤0.03 | ≤1.00 | 18.0-20.0 | 23.0-25.0 | 3.0-4.0 |
| Surface | Edge | Technique | Tolerance |
|---|---|---|---|
| 2B, BA, 8K Mirror, Drawing HL, N Titanium plating, Etching, Embossing | Mill Edge, Slit Edge | Cold Rolled / Hot Rolled | ±5% |
| Application | Advantage | Model Number | Packaging |
|---|---|---|---|
| Medical equipment, Food industry, Table-wares, Construction, Kitchen utensils, Chemical Industry | Strong Corrosion Resistance | Stainless steel sheet | Standard Seaworthy Package--wooden Pallet |
